Sale!
Vitronic18WVitronic18W

OASE Vitronic 18 W [INT]

Original price was: $500.90.Current price is: $455.35.

Key Features

  • Clear pond water via UVC clarification
  • Highly effective against suspended algae, bacteria and germs
  • Can be combined with almost all off the shelf filters

Characteristic

  • Elimination of suspended algae (green water)
  • Reduction of harmful bacteria and pathogen level
  • Visual function check of the UVC bulb
  • Quick release for easy bulb change and cleaning of the quartz glass
  • Direct installation on the BioSmart filter (only Vitronic 18-36 W)
  • High quality workmanship with impact resistant plastic housing
  • Easy installation thanks to an extensive range of connection accessories
  • Incl. high quality UVC bulb
  • 100% protection against eye damage
  • Suitable for ponds up to 20.0 m³
SKU: AQ-03OU002 Category:
Download Instructions

TECHNICAL DATA

Dimensions (L x W x H) mm 529 x 186 x 130
Rated voltage 220 – 240 V / 50/60 Hz
Power consumption W 18
Power cable length m 5.00
Net weight kg 2.12
Guarantee Years 2
UVC power W 18
Temperature display No
UVC operating hours meter No
Function check Visual
Number of inlets Units 1
Inlet connections mm 25 / 32 / 38
Inlet connections 1″, 1 ¼”, 1 ½”
Number of outlets Units 2
Connections, outlet mm 25 / 32 / 38
Outlet connections 1″, 1 ¼”, 1 ½”
Max. flow rate l/h 3500
Max. operating pressure bar 0.6
Suitable for ponds up to max. 20.0
Suitable for ponds with fish stock 10.0
Suitable for ponds with koi 5.0
Connection to BioSmart 18000/36000, BioTec ScreenMatic² 40 – 60000
Pos. Product SKU Quantity
1 Spare UVC electonics Vitronic 18 W 35839 1
2 Replacement bulb UVC 18 W UV18-2G11-4P-SE 1
3 Quartz glass D44 x 398 with rim 21763 1
4 Spare part clip bolt set UVC 18/ 36/ 55 15748 1
5 ASM waterhousing Vitronic 18 / 24 / 36 W 22206 1
6 Additional pack Vitronic new 35877 1
7 Flat gasket hose tail 1 1/2″ 19491 1
9 Cap nut 20 mm G 1 1/2″ 15445 1
